Technical Info
| Primary Voltage (V) | Secondary Voltage (V) | Tapping (%) | Frequency (HZ) | Vector Group | Impedance Voltage (%) | Ambient Temperature (°C) | Sea Level (Metr) | Cooling System | Primary Current (A) | Secondary Current (A) | No load Losses (W) | Load losses (W)
| Separate source voltage test (kV) | |
| Transformer Technical Data 25kVA – AB | 20000 | 400 | 4 | 50 | Yzn5 | 4 | 45 | 1000 | ONAN | 5/75 | 288/68 | 445 | 2760 | 50/3 |
Vestibulum curae torquent diam diam commodo parturient penatibus nunc dui adipiscing convallis bulum parturient suspendisse parturient a.Parturient in parturient scelerisque nibh lectus quam a natoque adipiscing a vestibulum hendrerit et pharetra fames nunc natoque dui.
Scelerisque adipiscing bibendum sem vestibulum et in a a a purus lectus faucibus lobortis tincidunt purus lectus nisl class eros.Condimentum a et ullamcorper dictumst mus et tristique elementum nam inceptos hac parturient scelerisque vestibulum amet elit ut volutpat.
| Primary Voltage (V) | Secondary Voltage (V) | Tapping (%) | Frequency (HZ) | Vector Group | Impedance Voltage (%) | Ambient Temperature (°C) | Sea Level (Metr) | Cooling System | Primary Current (A) | Secondary Current (A) | No load Losses (W) | Load losses (W) | Separate source voltage test (kV) | |
| Transformer Technical Data 25kVA - AB | 20000 | 400 | 5 | 50 | Dyn5 | 6 | 45 | 1000 | ONAN | 11/55 | 577/35 | 750 | 4600 | 50/3 |
| Primary Voltage (V) | Secondary Voltage (V) | Tapping (%) | Frequency (HZ) | Vector Group | Impedance Voltage (%) | Ambient Temperature (°C) | Sea Level (Metr) | Cooling System | Primary Current (A) | Secondary Current (A) | No load Losses (W) | Load losses (W) | Separate source voltage test (kV) | |
| Transformer Technical Data 25kVA - AB | 20000 | 400 | 4 | 50 | Yzn5 | 4 | 45 | 1000 | ONAN | 0/75 | 36/08 | 110 | 700 | 50/3 |
| Primary Voltage (V) | Secondary Voltage (V) | Tapping (%) | Frequency (HZ) | Vector Group | Impedance Voltage (%) | Ambient Temperature (°C) | Sea Level (Metr) | Cooling System | Primary Current (A) | Secondary Current (A) | No load Losses (W) | Load losses (W) | Separate source voltage test (kV) | |
| Transformer Technical Data 25kVA - AB | 20000 | 400 | 2*2.5 | 50 | Yzn5 | 6 | 45 | 1000 | ONAN | 14/4 | 722 | 875 | 5450 | 50/3 |
| Primary Voltage (V) | Secondary Voltage (V) | Tapping (%) | Frequency (HZ) | Vector Group | Impedance Voltage (%) | Ambient Temperature (°C) | Sea Level (Metr) | Cooling System | Primary Current (A) | Secondary Current (A) | No load Losses (W) | Load losses (W) | Separate source voltage test (kV) | |
| Transformer Technical Data 25kVA - AB | 20000 | 400 | 4 | 50 | Yzn5 | 4 | 45 | 1000 | ONAN | 2/89 | 144/34 | 260 | 1750 | 50/3 |
| Primary Voltage (V) | Secondary Voltage (V) | Tapping (%) | Frequency (HZ) | Vector Group | Impedance Voltage (%) | Ambient Temperature (°C) | Sea Level (Metr) | Cooling System | Primary Current (A) | Secondary Current (A) | No load Losses (W) | Load losses (W) | Separate source voltage test (kV) | |
| Transformer Technical Data 25kVA - AB | 20000 | 400 | 4 | 50 | Yzn5 | 4 | 45 | 1000 | ONAN | 1/44 | 27/17 | 145 | 1100 | 50/3 |
| Primary Voltage (V) | Secondary Voltage (V) | Tapping (%) | Frequency (HZ) | Vector Group | Impedance Voltage (%) | Ambient Temperature (°C) | Sea Level (Metr) | Cooling System | Primary Current (A) | Secondary Current (A) | No load Losses (W) | Load losses (W) | Separate source voltage test (kV) | |
| Transformer Technical Data 25kVA - AB | 20000 | 400 | 4 | 50 | Yzn5 | 4 | 45 | 1000 | ONAN | 0/75 | 36/08 | 110 | 700 | 50/3 |
