Showing all 11 results

Iran2Africa-15-HP-Tow-Speed-Evaporative-Cooler-Elctro-Motors-Product

1/5 HP Tow-Speed Evaporative Cooler Elctro Motors

$0.00

Product Specification

Type	Output Power	Output Power	Speed in rated load	Rated Current	Rated Torque	Power factor	Starting / Rated Current	Starting / Rated Torque	Break down / Rated Torque	Weight of foot mounting types	Capacitor Run	Capacitor Run	Poles
CR 80-4P	0.18	1/5	1400 -2Speed	1.8/1.6	1.2	0.96	2.18	1.05	2.27	5.370	8/8	400	1
CR 80-4P-S	0.18	1/5	1400-2Speed	1.5/1.2	1.2	0.94	2.3	1.05	2.27	5.380	8/8	400	1

Iran2Africa-Burner-Electro-Motors-Product

Burner Electro Motors

$0.00

Product Specification

Type	Output Power	Rated Voltage	Speed in rated load	Rated Current	Efficiency (%)	Power factor	Starting / Rated Current	Starting / Rated Torque	Break down / Rated Torque	Capacitor Run	Capacitor Run	Poles
EB90-21A	0.06	220	2690	0.55	52	−	2.3	0.8	1.6	4	400	1
EB90-21B	0.09	220	2800	0.75	57	0.96	2.8	0.82	2	5	400	1
EB90-21C	0.11	220	2700	0.85	60	−	2.4	0.65	1.4	6.3	400	1
EB90-21D	0.125	220	2730	1.01	56	1	2.64	0.82	1.67	6.3	400	1
EB90-21E	0.15	220	2710	1.15	61	−	2.8	0.63	1.6	6.3	400	1
EB90-21F	0.18	220	2700	1.25	67	−	3	0.43	1.4	6.3	400	1
EB90-21G	0.24	220	2700	1.7	66	0.97	3	0.35	1.44	8	400	1

Iran2Africa-Capacitor-Run-Two-Speed-Evaporative-Cooler-Electro-Motors-Product

Capacitor Run Two-Speed Evaporative Cooler Electro Motors

$0.00

Product Specification

Type	Frame size	Output Power	Output Power	Rated Voltage	Speed in rated load	Rated Current	Rated Torque	Power factor	Starting / Rated Current	Starting / Rated Torque	Break down / Rated Torque	Capacitor Run	Capacitor Run	Poles
CR 56-4/6-Col	56	0.187/0.062	1/4 / 1/12	220	1425/950	1.58/0.7	1.25/0.62	0.97/0.95	3.1	1.17	2.1/2.25	10/8	400/400	1
CR 56-4/6-D01	56	0.25/0.7	1/3 / 1/10	220	1425/950	2.3/1	2.1/0.98	0.96/0.98	3.69	1.14	1.85/0.97	16/8	400/400	1
CR 56-4/6-E01	56	0.37/.0124	1/2 / 1/6	220	1425/950	3.5/1.3	3.2/1.25	0.94/0.93	3.65	0.88	1.61/1.76	20/12.5	400/400	1
CR 56-4/6-F01	56	0.55/0.18	3/4 / 1/4	220	1425/950	3.75/1.69	3.75/1.87	0.99/0.97	3.6	0.56	1.73/1.25	25/12.5	400/400	1

Iran2Africa-Capacitor-Run-Capacitor-Start-Evaporative-Cooler-Electro-Motors-Product

Capacitor Run-Capacitor Start Evaporative Cooler Electro Motors

$0.00

Product Specification

Type	Frame size	Output Power	Output Power	Rated Voltage	Speed in rated load	Rated Current	Rated Torque	Power factor	Starting / Rated Current	Starting / Rated Torque	Break down / Rated Torque	Inertia moment	Capacitor Run	Capacitor Run	Capacitor Start	Capacitor Start	Poles
CRS 56-4/7	56	0.187/0.062	1/4 / 1/12	220	1425/950	1.58/0.74	1.25/0.62	0.97/0.95	3.5	1.68	2.1/2.25	0.00172	12/6	400/400	15	250	1
CRS 56-4/8	56	0.25/0.083	1/3 / 1/9	220	1425/950	2/0.9	1.67/0.83	0.98/0.96	4	1.6	2.26/0.97	0.00215	16/8	400/400	20	250	1
CRS 56-4/9	56	0.37/0.124	1/2 / 1/6	220	1425/950	2.9/1.18	2.5/1.25	0.95/0.97	3.44	1.52	2.2/1.76	0.002557	20/10	400/400	25	250	1
CRS 56-4/10	56	0.55/0.18	3/4 / 1/4	220	1425/950	3.68/1.69	3.75/1.87	0.99/0.97	3.2	1.53	1.6/1.25	0.003324	25/12.5	400/400	30	250	1

Iran2Africa-Circulator-Pump-Split-Phase-Electro-Motors-Product

Capacitor Start Two Speed Evaporative Cooler Electro Motors

$0.00

Product Specification

Type	Frame size	Output Power	Output Power	Rated Voltage	Speed in rated load	Rated Current	Rated Torque	Power factor	Starting / Rated Current	Starting / Rated Torque	Break down / Rated Torque	Inertia moment	Poles
CS 56-4/6	56	0.55/0.18	3/4 / 1/4	220	1425/950	5.5/2.9	3.75/1.87	0.795/0.665	4.25	1.45	1.56/1.83	0.02488	1

Iran2Africa-Circulator-Pump-Split-Phase-Electro-Motors-Product

Circulator Pump Split Phase Electro Motors

$0.00

Product Specification

Type	Frame size	Output Power	Output Power	Rated Voltage	Speed in rated load	Rated Current	Rated Torque	Power factor	Starting / Rated Current	Starting / Rated Torque	Break down / Rated Torque	Inertia moment	Poles
SP 56-4A	56	0.124	1/6	220	1425	2	0.83	0.612	6.35	1.9	2.38	0.001581	1
SP 56-4	56	0.25	1/3	220	1425	2.5	1.67	0.781	10.8	2.48	1.87	0.002488	1
SP56-4B	56	0.124	1/6	220	1425	1.4	0.83	0.754	8.26	1.96	2.1	0.002034	1
SP 56-4/6	56	0.25/0.07	1/3 / 1/10	220	1425/950	2.5/1.6	1.67/0.75	0.781/0.565	9.1	2	1.83/2.67	0.002488	1

Iran2Africa-Circulator-Pump-Split-Phase-Electro-Motors-Product

Circulator pump Split-phase electromotors

$0.00

Product Specification

Type	Frame size	Output Power	Output Power	Rated Voltage	Speed in rated load	Rated Current	Rated Torque	Power factor	Starting / Rated Current	Starting / Rated Torque	Break down / Rated Torque	Inertia moment	Poles
SP 56-4A	56	0.124	1/6	220	1425	2	0.83	0.612	6.35	1.9	2.38	0.001581	1
SP 56-4	56	0.25	1/3	220	1425	2.5	1.67	0.781	10.8	2.48	1.87	0.002488	1
SP56-4B	56	0.124	1/6	220	1425	1.4	0.83	0.754	8.26	1.96	2.1	0.002034	1
SP 56-4/6	56	0.25/0.07	1/3 / 1/10	220	1425/950	2.5/1.6	1.67/0.75	0.781/0.565	9.1	2	1.83/2.67	0.002488	1

Iran2Africa-New-Design-Burner-Electro-Motors-Product

New Design Burner Electro Motors

$0.00

Product Specification

Type	Frame size	Output Power	Output Power	Rated Voltage	Speed in rated load	Rated Current	Efficiency (%)	Power factor	Starting / Rated Current	Starting / Rated Torque	Break down / Rated Torque	Capacitor Run	Capacitor Run	Poles
ICR80-4A	80	0.55	0.75	220	1370	3.9	65	0.98	2.2	0.54	1.5	30	400	1
HCR80-4A	80	0.55	0.75	220	1370	3.9	65	0.98	2.2	0.54	1.5	30	400	1

Iran2Africa-PM-Evaporative-Cooler-Electro-Motors-Product

PM Evaporative Cooler Electro Motors

$0.00

Product Specification

Type	Output Power	Rated Voltage	Speed in rated load	Rated Torque	Power factor	Poles
PM3/4	0.55	175-250	600-1500	3.69	1	1
PM1/2	0.375	175-250	600-1500	2.51	1	1
PM1/3	0.25	175-250	600-1500	1.68	1	1

Iran2Africa-Portable-Two-Speed-Evaporative-Cooler-Electro-Motors-Product

Portable Two Speed Evaporative Cooler Electro Motors

$0.00

Product Specification

Type	Frame size	Output Power	Output Power	Rated Voltage	Speed in rated load	Rated Current	Weight of foot mounting types	Capacitor Run	Poles
PSC 80/4-6p	80	0.09 / 0.035	1/8 / 1/20	220	900/750	1/0.7	−	5	1

Iran2Africa-Split-Phase-Evaporative-Cooler-Electro-Motors-Product

Split Phase Evaporative Cooler Electro Motors

$0.00

Product Specification

Type	Frame size	Output Power	Output Power	Rated Voltage	Speed in rated load	Rated Current	Rated Torque	Power factor	Starting / Rated Current	Starting / Rated Torque	Break down / Rated Torque	Inertia moment	Poles
SP 56-4/6	56	0.187/0.062	1/4 / 1/12	220	1425/950	2.86/1.05	1.25/0.62	0.655/0.57	6.18	1.92	2.32/2.82	0.001883	1
SP 56-4/6	56	0.25/0.07	1/3 / 1/10	220	1425/950	3.2/2.1	1.67/0.75	0.69/0.531	5.6	1.62	2.15/2.69	0.002034	1
SP 56-4/6	56	0.37/0.124	1/2 / 1/6	220	1425/950	4.47/2.5	2.5/1.25	0.721/0.616	6.2	1.52	1.92/2.08	0.002488	1
